Ultrasonic Lace Sewing Machine
JSB Ultrasonic’s Ultrasonic Lace Sewing Machines bond non-woven fabrics, lace, and technical textiles using ultrasonic vibration instead of needle and thread — producing soft, strong, and consistent seams without puncturing the fabric. Our range covers non-woven bag making, diaper sealing, surgical gown assembly, and general lace/technical textile bonding.
Because there’s no needle, there are no puncture holes for fluid or particles to pass through — a key quality advantage for hygiene products, filtration layers, and medical-grade non-woven materials.
What is a Ultrasonic Lace Sewing Machine?
An ultrasonic lace/sewing machine uses a patterned roller and ultrasonic horn working together as fabric layers pass continuously through the machine. High-frequency vibration generates localized heat at the contact points, fusing fabric layers together in a continuous seam. Interchangeable pattern rollers let the same machine produce different seam styles for different products.
Key Features
- No needle, thread, or bobbin consumables required
- Strong, soft seams suitable for skin-contact products
- No puncture holes — important for filtration and hygiene items
- Continuous, high-speed seam bonding
- Interchangeable pattern rollers for multiple seam styles
- Consistent bond strength across the full seam length
Applications
Our ultrasonic lace sewing machines range is used across:
- Non-woven bag and carry bag manufacturing
- Diaper and hygiene product sealing
- Surgical gown and PPE assembly
- Non-woven lace trim bonding
- Face mask and technical textile production
Technical Specifications
| Parameter | Specification |
|---|---|
| Machine Type | Ultrasonic Lace / Sewing Machine |
| Frequency | 15kHz / 20kHz |
| Sewing Speed | Adjustable, continuous operation |
| Material Compatibility | Non-Woven Fabric, PE Film, Lace, Technical Textiles |
| Control System | Digital / PLC Based Control |
| Voltage | 220V / 380V |
| Warranty | 1 Year |
Why Choose JSB Ultrasonic?
JSB Ultrasonic supplies ultrasonic sewing and bonding machines to non-woven, hygiene, and technical textile manufacturers who need fast, hygienic, needle-free seaming. We match frequency, power, and pattern roller design to your specific fabric and seam requirement.
Frequently Asked Questions
What fabrics can this machine bond?
It is designed for non-woven fabric, PE film, lace, and technical textiles, producing strong seams without needle punctures.
Can the seam pattern be changed?
Yes, interchangeable pattern rollers allow different seam styles to be produced on the same base machine.
Is this suitable for continuous multi-shift operation?
Yes, the machine is built for continuous, high-speed operation across multiple production shifts.
Do you provide installation and training?
Yes, installation support and operator training are included so you can get the machine running correctly from day one.
Do you offer customization?
Yes, our engineers can review your part or application and recommend a customized fixture, horn, or configuration.
What after-sales support is available?
We provide spare parts, preventive maintenance guidance, and remote or on-site troubleshooting support for the life of the machine.
Buy Ultrasonic Lace Sewing Machine in India
We supply ultrasonic lace sewing machines to manufacturers in Delhi, Noida, Gurgaon, Faridabad, Bengaluru, Chennai, Sonipat, and across India, with export support internationally. Contact JSB Ultrasonic for a machine recommendation and quote tailored to your application.
